Archivo: ChuckDrillKeyedKeylessArbor
Descripción: Keyless and keyed drill chucks. The top image is an assembled (mounted on a 4 morse taper arbor) keyless chuck. The center images show an exploded assembly of a keyed chuck (Jacobs brand). At the left is an end view of the chuck with a side view in the middle, at the right is the arbor; a Jacobs No. 6 taper to fit the chuck with a 3 morse taper to fit the machine spindle. At the bottom is the chuck key used to operate the keyed chuck.
Título: ChuckDrillKeyedKeylessArbor
Créditos: Trabajo propio
Autor(a): Glenn McKechnie
Términos de Uso: Creative Commons Attribution-Share Alike 3.0
Licencia: CC-BY-SA-3.0
Enlace de Licencia: http://creativecommons.org/licenses/by-sa/3.0/
¿Se exige la atribución?: Sí
