Description: The motherboard of an Atari Lynx II, the revised version of the original Atari Lynx. This motherboard's manufactured or check date is November 21, 1991. Note that this board has had the aluminum RF shielding removed so that the chips underneath can be seen. The large chip on the board, the C301719-001 CPU, is called "Mikey" and the smaller one, the C302284-001, is called "Suzy." This particular board is listed as a Revision C104471-001 Rev. A model.
